Anti electromagnetic interference, non charged, non creepage, high sensitivity, accurate measurement, fast response speed, real-time online monitoring, corrosion resistance, fast and simple installati
Fiber Bragg Grating Temperature Sensor (Electric)
Model: ZZ-FBG-ET120-I
1、Summary
The Nanjing Zhunzhi ZZ-FBG-ET120-I type fiber optic grating power temperature sensor is mainly used for measuring power cabinets, switchgear, ground temperature, and other occasions with high temperature measurement accuracy and sensitivity。
The ZZ-FBG-ET120-I type fiber optic grating power temperature sensor is mainly packaged into a fully insulated temperature sensor through ceramic and Teflon high-temperature sleeves. It is suitable for occasions with strict requirements for electrification and creepage, such as temperature measurement of switchgear contacts, cable heads, transformer windings, etc。
2、Performance Parameter
Project | Company | Reference Value |
Standard Range | ℃ | -40~150 |
Accuracy | ℃ | 0.5 |
Resolving Power | ℃ | 0.1 |
Sensor Size | mm | Φ3*3*33 |
Center wavelength of grating | nm | 1527~1568 |
Maximum number of sensors per channel | Branch | 12 |
Sensor lead out and connectors | Single ended high-temperature PTFE optical cable or high-temperature nylon sleeve | |
Connection method between sensing heads | Parallel Connection |
